Bolt Series: New Standard
For High-Precision Laser Engraving
Bolt
Bolt Plus 24
Bolt Pro 36
Compact Precision for Everyday Creators
The Bolt delivers professional RF CO₂ engraving in a small footprint. Its compact size and fast speed make it ideal for makers, classrooms, and light commercial tasks. A perfect entry-level choice for users who need reliability without taking up space.
Technical data
| Machine Size (W x D x H) | 941*754*498 mm |
| Working Area | 508*305mm |
| Laser Source | RF CO₂ |
| Power | 30W |
| Max. Engraving Speed | 1500mm/s |
More Power, More Speed, More Possibilities
The Bolt Plus 24 expands capability with a 610 × 407 mm work area and speeds up to 2000 mm/s. Designed for studios and small businesses, it offers faster output and greater flexibility while remaining compact and easy to deploy.
Technical data
| Machine Size (W x D x H) | 1125*925*585 mm |
| Working Area | 610*407 mm |
| Laser Source | RF CO₂ |
| Power | 60W |
| Max Engraving Speed | 2000mm/s |
Professional Scale With Maximum Capability
As the series flagship model, the Bolt Pro 36 provides a large 915 × 610 mm work area, up to 80W RF CO₂ power, and 2000 mm/s engraving speed. Built for high-volume production and oversized projects, it delivers the highest performance and capacity in the series.
Technical data
| Machine Size (W x D x H) | 1430*1125*1225 mm |
| Working Area | 915*610 mm |
| Laser Source | RF CO₂ |
| Power | 80W |
| Max Engraving Speed | 2000mm/s |
Engineered for Accuracy
Up to 1,200 DPI Resolution
Fine As a Strand of Hair
Photo Realistic Engraving Quality
Details Down to Every Pore
0.01mm Accuracy
SPEED THAT DELIVERS
Up to 2000mm/s Max Engraving Speed
Up to 5G Acceleration
SMALL, COMPACT, POWERFUL
All-in-One Design
Exhaust & Air Pump Integrated
Just Plug and Play
Quality You Can Trust
All-Metal Structure
3-Steps QC SOP
A standardized 3-step quality control process ensures every Bolt is carefully inspected, tested, and verified before delivery, helping maintain reliable performance, consistent quality, and greater customer confidence.
100+ Check Points
Explore More
User-Friendly Designs
One-touch To Focus Precisely
Achieve the ideal focal distance in seconds with one-touch auto focus. This smart feature reduces manual setup, improves consistency, and helps users start engraving or cutting faster, ensuring precise results with less guesswork and a smoother workflow.
Cleaner Cuts, Sharper Details
Dual Air Assist delivers cleaner cuts, reduced scorching, and sharper engraving details by optimizing airflow exactly where it is needed.
With Rotary Tray Equipped
With rotary tray, you can quickly integrate rotary attachments for bigger cups, bottles, and other curved items without complicated adjustments, expanding creative possibilities while keeping operation simple, efficient, and production-ready.
High-Resolution Live View
The high-precision camera provides a clearer live view in laser software for accurate positioning and easier project alignment.
From batch production to custom pieces, it supports a faster, more visual, and more reliable workflow.
Explore Endless Creativity
With Thunder Bolt Series
-
Anodised Aluminum Engraving
-
Pens Engraving
-
Acrylic Cutting
-
Layers Cutting
-
Wood Coaster Engraving
-
Education and Toys
-
.jpg)
Glass Engraving
-
.jpg)
Slate Engraving
-
.jpg)
Dual-color Board Engraving
-
Fridge Magnet
-
.jpg)
Photo Engraving
-
Hat Patches Cutting
-
Football Engraving
-
Leather Openner Engraving
-
.jpg)
Stamp Engraving
-
.jpg)
Acrylic Necklace
MAKE IT HAPPEN WITH BOLT
Laser Source
Materials
Engraving
Cutting
RF CO₂
Wood
RF CO₂
Cork
RF CO₂
Acrylic
RF CO₂
Fabric
RF CO₂
Glass
RF CO₂
Plastic
RF CO₂
Mirror
RF CO₂
Bread
RF CO₂
Ceramics
RF CO₂
Stone
RF CO₂
Leather
RF CO₂
Rubber
RF CO₂
MDF
RF CO₂
Cardboard
RF CO₂
Slate
RF CO₂
Anodized Aluminium*
RF CO₂
Stainless Steel*
*CO₂ laser cannot process on bare metal directly but coated or painted metal.
TECHNICAL SPECIFICATIONS
Take a closer look at what the Bolt series has to offer.
*Swipe right to see all
|
Product Series
|
 BOLT
|
 BOLT PLUS 24
|
 BOLT Pro 36
|
| Machine Size | 941*724*498mm (37.0" x 28.5" x 19.6") |
1125*925*585mm (44.3" x 36.4" x 23.0") |
1430*1125*1225mm (56.3" x 44.3" x 48.2") |
| Working Area | 508*305mm (20.00" × 12.01") |
610 × 407 mm (24.02" × 16.02") |
915*610 mm (36.0" × 24.0") |
| Working Table | 557*357mm (22.00"x 14.00") |
715*483mm (28.15"x 19.02") |
1019*685mm (40.12"x 26.97") |
| Maximum Lifting | 110mm / 4.33" | 150 mm / 5.91" | 205 mm / 8.07" |
| Z Axis Height | 113mm / 4.45" | 160 mm / 6.30" | 210 mm / 8.26" |
| Max Part Size | 513 * ∞ * 110mm (20.20" x ∞ x 4.33") |
655 * ∞ * 150mm (25.79" x ∞ x 5.9") |
959 * ∞ * 205mm (37.76" x ∞ x 8.07") |
| Max Load | 10kg / 22.05 lbs | 20kg / 44.10 lbs | 20kg / 44.10 lbs |
| Machine Weight | 77kg / 169.76 lbs | 132kg / 291 lbs | 265.5kg / 585.3 lbs |
| Repeat positioning accuracy | 0.01mm | 0.01mm | 0.01mm |
| Max. scanning speed | 2,000 mm/s | ||
| Max. cutting speed | 300mm/s | 300mm/s | 300mm/s |
| Acceleration | 5G, 50,000mm/s² | 5G, 50,000mm/s² | 5G, 50,000mm/s² |
| Rotary Diameter | 0~90mm | 0~90mm | 0~90mm |
| Laser Type | 30W SPT RF Tube | 60W SPT RF Tube | 80W SPT RF Tube |
| Working Platform | Honeycomb Table | Honeycomb Table | Honeycomb Table |
| Laser head | Standard: 2.5" Optional: 1.5", 2.0", 4.0" |
Standard: 2.5" Optional: 1.5", 2.0", 4.0" |
Standard: 2.5" Optional: 1.5", 2.0", 4.0" |
| Pass-through Door | Front Pass-through Door | Front Pass-through Door | Front Pass-through Door |
| Rotary | Supported, Rotary Tray Included |
Supported, Rotary Tray Included |
Supported |
| Laser Source Lifetime / hour | 10,000+ | 10,000+ | 10,000+ |
| Voltage | 230V±5% or 110V±10% | ||
| Focus Lens | 1*20mm 2.5" CO2 Focus Lens | ||
| Reflector | 3*25mm CO2 Silicon Reflector | ||
| Beam Combiner | 1*25mm CO2 Beam Combiner | ||
| Window Mirror | / | 1*20mm CO2 Window Mirror | |
| Expander | 1*3x Divergence Angle-Adjustable CO2 Expander | ||
| Cooling System | Air Cooling | Air Cooling | Air Cooling |
| Air assist system | Dual-channel air assist with integrated digital flow meter | Dual-channel air assist with integrated digital flow meter | Dual-channel air assist with integrated digital flow meter |
| Nozzle | 3mm | 3mm | 3mm |
| Connections | Ethernet, USB Cable, USB Disk | Ethernet, USB Cable, USB Disk | Ethernet, USB Cable, USB Disk |
| Memory | 1GB (1024MB) | 1GB (1024MB) | 1GB (1024MB) |
| Software | LaserMaker, LightBurn, RDWorks Supported | LaserMaker, LightBurn, RDWorks Supported | LaserMaker, LightBurn, RDWorks Supported |
| Camera | 5MP Mounted Camera | 5MP Mounted Camera | 5MP Mounted Camera |
| Safety | FDA Class 1, CE | ||
See What They Say
About Thunder Bolt Series
-
Make or Break Shop
116k Followers
"Powered by an RF metal tube, the Thunder Laser Bolt delivers precision, speed, and reliability far beyond traditional glass CO₂ lasers. With fan-based cooling, there’s no need for bulky water chillers. Expect up to 1,000 DPI resolution, 0.01 mm accuracy, and engraving speeds reaching 1,000 mm/s. Features like autofocus with a touch probe, HD camera alignment, onboard memory, and a responsive touchscreen make every workflow simple and efficient. Compact in size yet professional in capability, the Bolt redefines what a desktop CO₂ laser can achieve."
-
Voeltner Woodworking
16.3k Followers
"Unlike traditional glass CO₂ lasers, the Bolt uses an RF metal tube for finer detail, faster engraving, and longer life—over 10,000 hours. No water chillers needed; cooling is fan-based. With up to 2,000 DPI resolution, 0.01 mm accuracy, and speeds reaching 1,000 mm/s, it’s precise and efficient. The machine includes autofocus, touch screen control, built-in memory, and an HD camera for easy setup. Compact yet powerful, it’s built for pros and hobbyists alike."
-
Laser NUG
5.0k Followers
"The Bolt sets itself apart from glass CO₂ lasers with an advanced RF metal tube, delivering sharper detail, faster engraving, and a lifespan exceeding 10,000 hours. Forget bulky water chillers—its efficient fan cooling keeps everything compact and reliable. Engineered for precision, it achieves up to 2,000 DPI resolution, 0.01 mm accuracy, and engraving speeds of 1,000 mm/s. With autofocus, a responsive touch screen, onboard memory, and an HD camera, setup and operation are effortless. Compact in size yet professional in capability, the Bolt is the upgraded solution for both hobbyists and professionals."
RELATED RESOURCES
-
Thunder Air
Junior Rotary
Bolt Plus 24 Stand
FROM SELECTION TO
EXPERT SUPPORT
1. Pricing & Purchase
Get a customized quote quickly. Enjoy transparent processes and one-stop support from order to setup via local service centers.
2. Material Testing
3. Laser Settings
4. Video Academy
5. Join the Partner Program
6. Book A Demo
FAQS ABOUT THUNDER BOLT
Q1: What are the main differences between the new Bolt Series and the previous models?
The new Bolt Series has been upgraded with faster engraving speeds (up to 2000 mm/s), higher RF power options (up to 80W), larger working areas, improved Z-axis height, and Standard dual-air assist. We also added a recessed tray design for larger rotary objects and included new accessories such as a conical nozzle.
Q2: Which Bolt model should I choose?
Bolt: Compact size, affordable entry-level RF laser engraver, great for hobbyists, schools, and makers.
Bolt Plus 24: Larger working area (610 × 407 mm), faster speed, and 60W RF tube — ideal for small businesses or frequent use.
Bolt Pro 36: Highest power (up to 80W) and largest size in the series — built for production, batch jobs, and professional users.
Q3: What materials can the Bolt Series engrave and cut?
The Bolt Series works with a wide range of non-metallic materials, including wood, acrylic, leather, paper, textiles, glass, and rubber. With proper settings, it can also mark coated metals.
Learn more materials that can be processed by Thunder Bolt in our Knowledge Base
Q4: What is the benefit of RF tubes compared to glass tubes?
RF tubes provide higher engraving precision, longer lifespan, faster response time, and more stable output compared to traditional glass tubes. This makes the Bolt Series ideal for professional applications.
Q5: How does the dual-air assist improve performance?
Dual-air assist separates high-pressure cutting air and low-pressure engraving air. This means cleaner cuts, reduced burn marks, and more efficient material processing.
Q6: What’s the advantage of the recessed tray design?
The recessed tray allows the machine to handle larger-diameter rotary objects, such as tumblers and bottles, expanding the range of possible applications.
Q7: Do the new models support rotary engraving?
Yes, all Bolt Series machines support rotary attachments, and the recessed tray design makes it easier to work with taller objects.
Q8: How easy is it to get started with the Bolt Series?
Every machine comes pre-calibrated, with intuitive software, step-by-step tutorials, and technical support. Most users can start engraving within no more than one hour of setup.
Q9: Is there a warranty and after-sales support?
Yes. All Bolt Series machines come with a warranty and access to Thunder Laser’s global support team. Free training resources and community support are also available.
